Name: Johnson Vee Wire Wrapped Screen Stainless Steel 114-500mm
Brand: Anping County Hengyuan Hardware Netting Industry Product Co.,Ltd.
SKU: 12-3/4" 10-3/4" 8-5/8" 6-5/8"
Price: 100.00 USD
Availability: InStock

Haus > PRODUKTE > Johnson Vee Wire Screen >

Johnson Vee Wire Wrapped Screen Stainless Steel 114-500mm

Johnson Vee Wire wrapped screen

stainless steel well screen

114-500mm Johnson Vee Screen

Herkunftsort:

Hengshui, Hebei, China

Markenname:

Heng Yuan

Zertifizierung:

ISO9000

Modellnummer:

12-3/4" 10-3/4" 8-5/8" 6-5/8"

Treten Sie mit uns in Verbindung

Fordern Sie ein Zitat

Produkt-Details

Name:

Draht wickelte Schirm ein

Material:

Edelstahl und kohlenstoffarmer Stahl

Durchmesser:

114 bis 500 mm

Länge:

bis zu 6000 mm

Größe der Schlitze:

0.05-100mm

Verpackungsdraht:

1.5*2mm, 2*3mm, 2*3.5mm, 2.2*3.5mm, 3*5mm

Stützstange:

ø4,0 mm und andere

Endverbindung:

Mann/weibliches verlegt

Paket:

Kunststofffolie

Verwenden:

In den Wasserbrunnen zur Sandsteuerung

Verwandte Produkte

6-5/8" SS304L Johnson Vee Wire Screen Pipe for Sand Control

Erhalten Sie besten Preis

Video

Kohlenstoffarmer verzinkter Johnson-V-Drahtschirm 8-5/8" 100 Bar Kollapsfestigkeit

Erhalten Sie besten Preis

Video

Od 16" Hohe Festigkeit Johnson Vee Draht Schirm für Wasserbrunnen

Erhalten Sie besten Preis

Video

Hochfester 6 Meter Johnson Vee Wire Screen 205/304/Grad 304L/316L

Erhalten Sie besten Preis

Treten Sie mit uns in Verbindung

86-318-7565918

hengyuan1@aphywire.com

86-318-7565919

Kontakt jetzt

Produkt-Beschreibung

Johnson Vee-Shaped Wire Wrapped Screen Machine

Product Overview

High-performance wire wrapped screen designed for water well sand control applications, available in various materials and configurations to meet specific filtration requirements.

Key Specifications

Material: Stainless steel and low carbon steel options
Diameter Range: 114-500mm (3"-18")
Length Options: Up to 6000mm (standard 2.9m/3m and 5.8m/6m)
Slot Size: 0.05-100mm (standard 0.5mm, 0.63mm, 0.75mm, 1.0mm, 1.5mm)
Wrap Wire: Multiple size options including 1.5×2mm to 4×7mm
Support Rod: ø3.0-ø6.0mm round wire or Vee-shaped wire
End Connections: Male/female threaded, welded rings, plain beveled ends, or flange
Surface Finish: Polished
Package: Plastic film wrapping

Standard Specifications

Size (inch)	OD (mm)	Slot (mm)	Length (m)	Tensile Strength	Collapse Strength	Wrap Wire (mm)	Support Rod (mm)
3-1/2	88.9	1.0	2.9	＞22	10.2	2.0×3.5	ø3.8×22
4-1/2	114.3	1.0	2.9	＞28	11.5	2.0×3.5	ø3.8×22
6-5/8	168.3	0.75	5.8	＞40	12.8	2.0×3.5	ø3.8×32
6-5/8	168.3	1.0	5.8	＞33	12.8	2.2×3.5	ø3.8×32
8-5/8	219.1	1.0	5.8	＞50	38.2	3.0×4.6	ø4.0×48
10-3/4	273.1	1.0	5.8	＞60	39.5	3.0×4.6	ø4.8×55

Applications

Water well sand control
Oil well filtration
Waste water treatment systems
Water supply infrastructure
Coal and mining operations
Food processing and beverage screening
Environmental protection systems
Refining and petrochemical applications
Architectural and construction uses

Customization Available: Special specifications can be manufactured according to your specific requirements.

Note: All specifications are subject to manufacturing tolerances. Contact us for detailed technical drawings and exact specifications.
